Chapter 3 – Using your Wireless Modem
Connecting to the Internet
Internet access can be setup in Windows Dial-Up Networking (DUN) of the computer that the MultiModem Cell is serving. For a
GPRS network, you have to create an Access Point Name in the Phone and Modem Options dialog in Windows Control Panel
and then create your Windows Dial-Up Connection (DUN).
Connecting to a CDMA Network for Internet Access
Once you have activated your wireless account, you can establish your Internet connection through a Windows dial-up session.
Setup procedures will vary according to the type of wireless service provider used.
Requirements
●
●
●
One CDMA capable MultiModem Cell modem
The modem must be getting a proper signal and be showing a network registration through the wireless provider’s
network
A PC running Windows 7, Vista or XP with the Multi-Tech drivers installed for your particular model
The following instructions are for Windows Vista or XP. Every PC may have slight differences which may cause the instructions
to be different. Use these instructions as a guide to help you understand what is required to set up an Internet connection
through your wireless service provider for all operating systems.
Connecting to an EDGE/GPRS Network for Internet Access
After you have inserted the SIM card and all other setup steps are complete, you can establish an Internet connection through a
Windows dial-up session.
Requirements
●
●
●
●
One EDGE capable MultiModem Cell modem
The MultiModem Cell modem should have an EDGE capable network and an active SIM card
The modem must be getting a proper signal and be showing a network registration through the wireless provider’s
network
A PC running Windows 7, Vista or XP with the Multi-Tech drivers installed
The following instructions are for Windows 7, Vista and XP. Every PC may have slight differences which may cause the
instructions to be different. Use these instructions as a guide to help you understand what is required to set up an Internet
connection through your wireless service provider for all operating systems.
Set the Access Point Name (APN) into the Modem’s Properties on your PC
In order for your EDGE modem to connect to your provider’s network, you must tell the modem the APN to which it will
connect. The APN is a server name that your account is setup on with your provider. Your APN will be given to you by your
provider. Here are some well known APNs:
●
●
●
AT&T; PROXY, or INTERNET, or PUBLIC
T-Mobile: INTERNET2. VOICESTREAM.COM, or INTERNET3.VOICESTREAM.COM, or WAP.VOICESTREAM.COM
Rogers AT&T of Canada: INTERNET.COM
Setting up an Access Point Name (APN)
20
●
●
●
●
●
●
Click on the Start button and then Control Panel .
In Control Panel, double-click on Phone and Modem Options.
In the Phone and Modem Options screen, click on the Modems tab. Highlight your Cell modem listed in the table
and then click on Properties .
A Properties window for your modem will display. For Windows Vista and later operating systems, click on the
Change Settings button.
Click on the Advanced tab. You should see an Extra Settings box. In the Extra initialization commands text box,
enter:
AT+CGDCONT=1,”IP”,”<APN>”
For <APN>, enter in the correct APN for your account.
For example: AT+CGDCONT=1”IP”,”ISP.AT&T”
Click OK to close the Properties window. Then click OK to close the Phone and Modems Options window.
Multi-Tech Systems, Inc. MultiModem Cell User Guide
